China peristaltic pump is a new type of multifunctional industrial pump developed by absorbing foreign advanced technology. China peristaltic pump completely eliminates the working methods of the traditional pump impeller and shaft seal, and has great advantages in conveying media containing high viscosity, high corrosion and a large amount of fluid impurities. Based on a completely different principle from traditional pumps, it has a wider range of applications and can be used in chemical, petroleum, water treatment, medicine, food, metallurgy, mining, construction, building materials, ceramics, paper and other industries.

The working principle of the China peristaltic pump is mainly: a pair of rollers rotate in the pump cavity filled with lubricant, and the roller and the wall of the peristaltic pump housing cavity push the hose together and flatten the hose. As the roller rotates, the flat part of the hose gradually moves from the inlet end to the outlet end of the pump. In this process, the liquid-filled hose gradually returns to its original shape due to its own elastic action, thereby increasing the volume and creating a vacuum for suction of materials, while the liquid-filled hose gradually returns and is extrusion.

As the China peristaltic pump supplier, the China peristaltic pump has the following functions:

1. Low speed, no noise, and can be idling.

2. Unique structure, no seal, no leakage.

3. China peristaltic pump has a strong self-priming ability.

4. The peristaltic pump has simple structure and convenient maintenance.

5. China peristaltic pump can transport corrosive slurry and sludge with high content of particles, fibers and other impurities.

6. The medium flow rate is low and there is no shearing force, especially suitable for bearing materials sensitive to shearing force.

7. China peristaltic pump can transport high-viscosity media, and can also transport gas, liquid and solid three-phase mixed media, and has the cleaning ability.

8. By adjusting the speed of the China peristaltic pump, the flow can be adjusted without changing the outlet pressure of the pump.

9. If the speed is constant, adjusting the outlet valve will change the outlet pressure of the pump, but the flow will basically not change. Therefore, the pump has a specific weighing function and can be used as a weighing pump.

As the peristaltic pump supplier, we should advise everyone that extending the service life of peristaltic pumps lies in the way and strength of the compressed hose. Insufficient compression will cause internal leakage and backflow, reduce volumetric efficiency, and severely wear the inner cavity of the hose, especially under high pressure; excessive compression will increase bearing load and consumption. Even if the hose is over-compressed by 1 mm, the life of the hose will be reduced by about 25%. Please follow the factory instructions for easy operation and maintenance.
