This product is a kind of plunger mortar spraying pump, which is produced and improved on the introduction of Germany advanced technology. This high pressure mortar pump is mainly applied to the external walls of solid plaster mortar spraying, external wall insulation mortar spraying, mortar roughcast, refractory material spraying, large area of building fire-proof material spraying; Waterproofing agent spraying and varieties of shotcrete bolt support engineering.

This mortar spraying machine is mainly applied to the external walls of solid plaster mortar spraying, external wall insulation mortar spraying, mortar roughcast, refractory material spraying, large area of building fire-proof material spraying; Waterproofing agent spraying and varieties of shotcrete bolt support engineering.

High pressure, no pulse;
Higher production efficiency, compact structure;
Easy to move and service.

GEC-SUB8.0 High Pressure Mortar Spraying Pump
Item	Value
Throughput	4-8m3/h
Maximum operation pressure	8Mpa
Mortar level of transmission distance	100-150m
Mortar vertical conveying distance	30/45m
Maximum transmission gray sand ratio	1:2.5
Vibrator	0.75kw
Host power	11kw
Total weight	700kg
