Plate And Frame Filter Press for sale

Applications: Chemicals, dyes, petroleum, ceramics, pharmaceuticals, sugar, starch, paint, metallurgy and waste water treatment.

Product features: Plate and frame filter presses are suitable for large or near incompressible suspensions. Suitable suspensions typically have a solids concentration of less than 10% and an operating pressure of generally from 0.3 to 1.6 MPa, particularly up to 3 MPa or higher. The filter area can be increased or decreased depending on the number of plate frames used. The plate frame is usually square.

The inner side of the filter frame is 200-2000 mm long, the frame thickness is 16-80 mm, and the filter area is 1-1200 m2. The plate and frame are pressed by manual screw, electric screw and hydraulic pressure. The plates and frames are made of wood, cast iron, cast steel, stainless steel, polypropylene and rubber.

Advantages: The utility model has the advantages of simple structure, easy operation, stable operation and convenient maintenance; the filter area has a flexible selection range and a small occupation area; and has strong adaptability to materials, and is suitable for various small and medium sludge dewatering treatment occasions.
