Machine type:GSZ-10S/E
Power supply:AC380V 50Hz three-phase
Motor power :7.5kw

Type:GZ-9E/S
Rotor Volume:12.9L
Max. Rotor Speed:12.6r/min

Rated Output:5m3 /h
Max. Horizontal Conveying Distance:35m(wet) /200m(dry)
Max. Aggregate Size:15mm

Output:1.5-3m3/h
Max. Aggregate:10mm
The Squeeze Hose:ID 50mm

Concrete Spraying Machine Type:Rotary machine GSZ-10S
Process:Thin-stream
Air motor type:TMH8A

Model:GZ-3A
Output Capacity:1.5~3m3/h
Suitable Mix Ratio(Cement/Sand):≤1:3~5

Output Capacity:9m3 /h
Max. Horizontal Conveying Distance:200m
Suitable Mix Ratio(Cement/Sand):≤1:4~5

output:5-8m3/h
Max. pressure:8MPa
Distribution valve type:S valve

Rated Output:5m3 /h
Max. Horizontal Conveying Distance:200m
Suitable Mix Ratio(Cement/Sand):≤ 1.3~5

Rated Output:7m3/h
Max. Aggregate Size:20mm
Conveying Hose Inner Diameter:51/64mm

Output Capacity:3m3 /h
Max. Horizontal Conveying Distance:200m
Suitable Mix Ratio(Cement/Sand):≤1:3~5

Pump head:GH50-680
Output:6-8m3/h
Max. Aggregate:10mm

Drive Type:Electric motor
Working Pressure:2.5Mpa (Trelleborg Hose)
Output:4-8m3/h

Model:GDUH15A-A
Pumping output:100-600 L/h
Air motor power:4 KW

Arm structure:main arm rotate+telescope, spray arm rotate+telescope
Max. Spray depth:8m
Max. Spray width:2m×14m

L×W×H:7100mm×2150mm×2700mm
Max. Spray height:8m
Max. Spray width:12m

L×W×H:7150mm×2150mm×3000mm
Max. Spray height:13m
Max. Spray width:2m×11m

Drive mode:electric motor work
Electric motor rated power:52KW
Max. Spray height:15m

L×W×H:7800x2530x3280mm
Max. Spray height:15m
Max. Spray width:2×13m

L×W×H:7800x2530x3280mm
Max. Spray height:15m
Max. Spray width:2×13m

Rated output:5-15m³/h
Rated pressure:4MPa
Max. Rated vertical distance:50m

Rated output:5-15m³/h
Rated pressure:4MPa
Max. Rated vertical distance:50m

Rated output:2-5m3/h
Max. horizontal conveying distance:35m(wet)/200m(dry)
Max. aggregate size:15mm

Productivity:7m3/h
Max. particle size:15mm
Concrete slump:8～15cm

Parameters:GPS10/80
The output:5-10 m3/h(adjustable)
Output pressure:80bar
